Custom LED Sign | Interchangeable Pictograms

Base Code: LEDCU

Items marked FAST SHIP typically ship same day if order is placed before noon

Custom LED Sign | Interchangeable Pictograms
Processing...

Get Help

Lead Time:
User Provided Artwork - 3-4 Week

Qty

Now offering custom LED Sign with interchangeable slide-in pictograms. Sophisticated and practical solution that seamlessly combines quality LED illumination with modern soft corner styling. This attractive LED sign is not only eye-catching but also incredibly easy to install and versatile, making it an ideal choice for a wide range of applications. Designed to have interchangeable pictograms to properly mark path of egress, restroom access, area of rescue and more. Available in white and black housing as well as red, blue or green artwork/custom wording.

Available Pictograms:




Compatible Battery:  3.6V 1000mAh

This product has been tested to meet all required U.S. standards by Underwriters Laboratories, Inc. (UL), the most widely recognized U.S. nationally recognized testing laboratory (NRTL).

UL Listed
This item has been tested and meets safety standards imposed by the Underwriters Laboratories (UL).

LED Lighting

LED Lighting
This product uses energy efficient and long lasting LED's.

Battery Included

Battery Included
This product contains a battery for backup power. The battery must be connected during installation.

Features

  • UL Tested for USA and Canada Markets
  • Interchangeable Pictrograms
  • All LED light! No SLA batteries, uses long lasting NiCads that are very low maintenance
  • 120V-347VAC Operations
  • Universal mounting canopy for ceiling, wall, and side mount
  • Lightweight with snap-together construction for easy installation
  • LED status indicator
  • Injection molded, impact- and scratch-resistant, corrosion-proof, UL 94 V-0 flame retardant housing
  • Push-to-test switch

Specifications

Dimensions (May Vary by Model)
Height9.05"
Depth2.16"
Length13.5"
Weight4.00 lb

What's included?

  • LED Sign
  • Custom Pictogram. Comes with two of the selected pictogram, so the unit can be double-sided.
  • One Blank Faceplate
  • Mounting Canopy, Installation Instructions & Hardware (Inside Unit)
  • NiCad Battery - Must connect the battery after installation

Construction

The LEDCU Sign series is constructed from injection molded thermoplastic ABS housing, plastic enclosure 5VA flame retardant housing.

Emergency Operation

Upon failure of the normal utility power, an internal solidstate transfer switch automatically provides uninterrupted emergency operation for at least 90 minutes. The fully automatic solid-state, two-rate charger initiates battery charging to recharge a discharged battery in 24 hours.

Battery - Battery Backup

The LEDCU Sign series is designed with a maintenance-free 3.6V 1000mAh NiCad battery that provides a minimum emergency duration of 90 minutes. Recharge time of the battery is 24 hours.

Operational Temperature

Temperature Ratings
Series Temperature
Standard 50°F to 95°F

Electrical Components

Universal 120V-347VAC operation. LED display indicates AC/ON. An external push button test switch with battery backup units allows maintenance personnel to quickly determine the operational status of the unit. Unit offers surge protected, solid state circuitry.

Installation

The LEDCU Sign series is suitable for wall, side or ceiling installation via included mounting plate. Snap together design allows for quick and easy installation.

Mounting Configurations   Mounting Configurations Explained

PDF Download   View Installation Instructions

Dimensions

Custom LED Sign | Interchangeable Pictograms Dimensions

Customer Questions & Answers
Post a question and have an expert answer



Q Allison Erickson • 04/16/2024, 7:06:39 PM Can you print all colors for the custom signage? We would like to use our brand colors. Thanks
A Exit Light Co. Depending on the artwork submitted, yes, the factory can produce multicolored signs. Please send a copy of the proposed artwork to orders@exitlightco.com with a request to find out if it can be produced for the LEDCU.
