Edge Lit Universal Red and Green LED Exit Sign | Adjustable Angle | Wall, Ceiling, and Side Mount

Base Code: ELRT-U

Items marked FAST SHIP typically ship same day if order is placed before noon

Edge Lit Universal Red and Green LED Exit Sign | Adjustable Angle | Wall, Ceiling, and Side Mount
Processing...

Lead Time:
DC Operation Type - Nov 2024
White and Black Housing 3-5 Days

Qty

Introducing the Universal Color LED Exit Sign, the first of its kind in the market. This edge-lit exit sign offers unparalleled versatility with its field-selectable color feature, allowing you to switch effortlessly between red and green LEDs based on your specific needs. Designed for maximum flexibility, this exit sign features an adjustable angle for optimal visibility in any space. Whether you need a ceiling, wall, or side mount configuration, this exit sign adapts seamlessly to any installation environment. Perfect for ensuring safety and compliance, this versatile exit sign is a smart choice for any setting, offering both functionality and sleek, modern aesthetics.

Compatible Battery: 3.6V 300mAh

Input Wattage: Battery Backup - 3.5W / AC Only (No Battery) - 2.4W

How To: Replace battery and faceplates

This product has been tested to meet all required U.S. standards by Underwriters Laboratories, Inc. (UL), the most widely recognized U.S. nationally recognized testing laboratory (NRTL).

UL Listed
This item has been tested and meets safety standards imposed by the Underwriters Laboratories (UL).

LED Lighting

LED Lighting
This product uses energy efficient and long lasting LED's.

Battery Included

Battery Included
This product contains a battery for backup power. The battery must be connected during installation.

Features

  • UL 924, NEC, OSHA and NFPA 101 Life SafetyCode
  • Listed for damp location
  • Field Selectable Red and Green
  • Most versatile edge lit exit sign on the market
  • Wall, sloped, high, or standard ceiling and recessed mount available
  • Aluminum housing with high grade acrylic face
  • Field Installable Arrows for Left, Right or Both directions.
  • Long life LED illumination
  • Test switch and charge rate indicator on battery backup models
  • Dual 120/277 volt operation
  • CEC Compliant

Specifications

Dimensions (May Vary by Model)
Width12.13"
Height9.75"
Depth1.75""
Weight5.00 lb

What's included?

  • LED Exit Sign
  • Clear Single Sided "EXIT" Faceplate (with optional adhesive arrows)
  • Mirrored Double Sided "EXIT" faceplate (extra cost)
  • Mounting Canopy, Installation Instructions & Hardware
  • NiCad Battery - Must connect the battery after installation

Construction

The ELRT-U Edge Lit Exit Sign housing is constructed of die-cast aluminum housing with an etched, clear acrylic panel. Double sided panel comes as mirrored configuration. Lettering is 6” high with 3/4” stroke. Aluminum housing is standard, black and white housing available.

Illumination

The ELRT-U Exit Sign series delivers long-lasting LED illumination with a high-output LED board that includes both red AND green options (Red is set as default). The energy-efficient design consumes less than 3 watts for AC-only models, while battery backup units are rated at less than 4 watts, ensuring reliable performance with minimal energy use.

Emergency Operation

Upon failure of the normal utility power, an internal solidstate transfer switch automatically provides uninterrupted emergency operation for at least 90 minutes. The fully automatic solid-state, two-rate charger initiates battery charging to recharge a discharged battery in 24 hours.

Battery - Battery Backup

The ELRT-U series is designed with a 3.6V 300mAh maintenance-free NiCad battery. The battery is protected by a low voltage cut-off circuit.

Operational Temperature

Temperature Ratings
Standard Option 50°F to 104°F

Self-Testing Option


Electrical Components

Dual voltage input 120/277 VAC operation. LED display indicates AC/ON. An external push button test switch allows maintenance personnel to quickly determine the operational status of the unit. Unit offers brown out, overload and short circuit protection.

Installation

The ELRT-U is versatile and adaptable, suitable for mounting on walls, sloped or side surfaces, as well as high or standard ceilings. It comes with field-installable directional arrow indicators for added flexibility. All necessary hardware is included for a hassle-free installation.

Mounting Configurations   Mounting Configurations Explained

PDF Download   View Installation Instructions

Dimensions

Edge Lit Universal Red and Green LED Exit Sign | Adjustable Angle | Wall, Ceiling, and Side Mount Dimensions
